Mechanical Vertical Impeller Valve Bag Filler
Model 8400
Model 8400 is semi-automatic machine designed to bag fine powders without the need for a lot of sophisticated technology. Training, operation, cleaning, and maintenance are easy and straightforward. It comes with many superb features from our valve bag filler line: simple air operated controls to start and stop the machine; a mechanical scale for easy bag weight adjustment; a rotary turbine to rapidly move materials as if they were liquid; high output speeds at up to 10 bags per minute; heavy wall construction for rugged use and durability; and a removable bottom door for safe and easy interior access.

Examples of Materials Bagged with this Machine
Portland cement, masonry cement, flyash, calcium carbonate, plaster, mortars, bentonite, gypsum

Powders
Specifications:

Bag filling weight range: 20-110 lbs. (9-50 kg)

Production rate: 1-8 bags per minute (material and bag size dependent)

Material density range: 50-130 lbs. (22.7-59 kg) per cubic foot

Operating modes: Semi-automatic (operator assisted)

Bag types: Internal sleeve and/or tuck-in sleeve perforated paper, plastic film, and poly woven bags
